LS Vertical Die Spotting Press Machine

Aquamate die spotting press machines fit the needs of high precision die spotting requirement. Via simple and safe operations, the machines are efficient for quick die/mold tryout in supporting precision mold production. The operation mode is simple which requires only single person to complete the task.

Product Highlights:

  • Specially for medium and large size molds
  • Fully computerized control with Siemens PLC and touch-screen display
  • Uniform die spotting ink via computerized pressure adjustment
  • Permanent electro-magnetic clamping technology instead of clamping bolts
  • Permanent magnetic protection to keep molds staying in position despite power outage
  • Mold-carried tuning angle between 0 - 180° (upper plate)
  • Models with turning capacity from 1 ton to 30 tons
  • Rotation driven by hydraulic pressure
  • Classic bolt-mount configuration also available

LS Vertical Die Spotting Press Machinev1.1


Download PDF

LS-300 Vertical Die Spotting Press Machine with Rotary Plate

Aquamate die spotting press machines fit the needs of high precision die spotting requirement. Via simple and safe operations, the machines are efficient for quick die/mold tryout in supporting precision mold production. The build-in rotary plate facilitates the swapping operation between Single / Double / Tri-Shot Mold.

Product Highlights:

  • Specially for multi-injection molds
  • Fully computerized control with touch-screen display
  • Permanent electro-magnetic clamping technology without the need of clamping bolts
  • Permanent magnetic protection to keep molds staying in position despite power outage
  • PMold-carried swinging angle between 0 - 180° (upper plate)
  • Drum rotating positions at 0°, 120° and 240° or 0°, 180° via touch panel control
  • Uniform die spotting ink via computerized pressure adjustment
  • Safe and reliable
  • One-man operation

LS-300 Vertical Die Spotting Press Machine with Rotate Platev3.0


Download PDF

WS Horizontal Die Spotting Press Machine

Aquamate die spotting press machines fit the needs of high precision die spotting requirement. Via simple and safe operations, the machines are efficient for quick die/mold tryout in supporting precision mold production. The operation mode is similar to horizontal injection molding machine which requires only single person to complete the task.

Product Highlights:

  • Specially for small and medium sized molds
  • Fully computerized control with Siemens PLC and touch-screen display
  • Dual rotatable magnetic plates
  • Tie bar construction for accurate magnetic plate movement
  • Permanent electro-magnetic clamping technology instead of clamping bolts
  • Permanent magnetic protection to keep molds staying in position despite power outage
  • Uniform die spotting ink via computerized pressure adjustment
  • Models with turning capacity from 1 ton to 8 tons
  • Rotation driven by hydraulic pressure
  • Compact size with just ¼ volume of similar machines

WS Horizontal Die Spotting Press Machinev1.1


Download PDF

MNLW Die Spotting Press Machine

Aquamate MNLW die spotting press machine is built with tie bar construction that makes panel leveling highly stable and precise.It is ideal for maintenance, repair and cleaning work of small to medium high precision molds and dies.

Product Highlights:

  • A tie bar construction vertical die spotting press machine with excellent panel leveling
  • Specially for high precision small to medium size molds and dies
  • Fully computerized control with touch-screen display
  • Permanent electro-magnetic clamping technology without the need of clamping bolts
  • Permanent electro-magnetic clamping technology instead of clamping bolts
  • Permanent magnetic protection to keep molds staying in position despite power outage
  • Mold-carried swinging angle between 0 - 180° (upper plate)
  • Uniform die spotting ink via computerized pressure adjustment
  • Optimum working table height
  • Light weight --- concrete foundation not necessary
  • Safe and reliable
  • One-man operation

MNLW Die Spotting Press Machinev3.0


Download PDF

KMF Mold Open-Turn Machine

Aquamate mold open-turn machine provides a safe and efficient way in handling molds and dies. It is ideal for maintenance, repair and cleaning work of small and medium molds and dies.

Product Highlights:

  • Simple operation with wired touch screen remote control
  • Dedicated for small and medium sized molds maintenance work such as inspection and cleaning
  • Tilting and horizontal movement driven by hydraulic pressure
  • Dual rotatable magnetic plates with the ability to turn both mold plates simultaneously
  • Electro-permanent magnetic clamping technology without the need of clamping bolts
  • Permanent magnetic protection to keep molds staying in position despite power outage
  • Light weight --- concrete foundation not necessary
  • Safe and reliable
  • Models with turning capacity from 1.5 tons to 5 tons

KMF Mold Open-Turn Machinev2.0


download PDF

PMF Flat Panel Mold Turning Machine

Aquamate mold turning machine is an indispensable auxiliary equipment for turning medium to large sized molds. It is the perfect counterpart to be used in conjunction with any vertical die spotting press machines. It is also the ideal equipment for repairing any large sized molds.

Product Highlights:

  • For repairing medium to large size molds
  • Simple operation via wired control unit
  • Rotation driven by mechanical cogs via hydraulic pressure
  • Low working table
  • Compact size
  • Models with turning capacity from 5 tons to 50 tons

PMF Flat Panel Mold Turning Machinev1.1


download PDF

MF 90 Degree Mold Turning Machine

Aquamate mold turning machine is an indispensable auxiliary equipment for turning medium to large sized molds. It is the perfect counterpart to be used in conjunction with any vertical die spotting press machines. It is also the ideal equipment for repairing any large sized molds.

Product Highlights:

  • For repairing medium to large size molds
  • Simple operation via wired control unit
  • Auto-locking function activates during power outage to hold the mold firmly at its position to prevent the risk of being tipped over
  • Low working table
  • A perfect counterpart in conjunction use with any vertical mold fitting machines
  • Models with turning capacity from 5 tons to 50 tons

MF 90 Degree Mold Turning Machinev1.1


download PDF
